GL4-E

The outstanding customer satisfaction with an abundance of accessories. Ideally suited for the volume production of 2W crankshafts, automotive parts & similar cylindrical components, high productivity, high accuracy and easy operation with standardize of Fanuc control.

AVAILABLE MACHINE SEARCH BY INDUSTRY
SPECIFICATION
ITEMS
UNIT
GL4A - 32E / GL4P - 32E
Swing over table
mm
Ø320
Distance between centers
mm
320
Grinding diameter
mm
Ø0 ~ Ø220
Max load between centerskg150
Wheel


     Size (OD x Max Width)
mm
Ø610 x 125 x Ø254
     Surface speed
m/s
45 [60]
Wheelhead


     Rapid feed rate
m/min
Ø20
     Minimum input increment
mm
Ø0.0001
Machine weight
kg4,500

 *The specifications may be restrained according to the accessories and the tooling of customer.
[ ] : optional

The outstanding customer satisfaction with an abundance of accessories  with standardized by Fanuc controller

High productivity
     • Designed for automotive mass production concept
     • Abundance of accessories as standard

High - Accuracy
     • JTEKT STAT BEARING
     •  High rigidity bed
     •  Machine structure reducing the effect of heat

Easy Operation
     •  Fanuc control
     •  Visualization of maintenance and repair work
